Introduction :

7in1- Diameter 45.0mm ,Height 10.0mm easily sealable TIR-lenses for up to 3535 ,3030,2525 size LED packages.
For example :
CREE XP-E,XP-G/G2,XP-L,XT-E;
CREE XB-D,XQ-E;
OSRAM SSL80,SSL150,Square;
Seoul Z5P,Z5M;
Luxeon T,Federal 3535;
LG 3535, Samsung 3535;
Nichia 119A;


Part No.

Dim. (mm)

Beam Angle
(Field Angle)

Notes

7in1- 45mm-10degree CREE XPE,OSRAM OSLON 3535,3030,Multi LED Lens
HX-C45Bx7-10(clear surface)
HX-C45Bx7-10L (beads surface)
HX-C45Bx7-10M (frosted surface))
¢45.0
H 10.0
10°

7in1- 45mm-15degree CREE XPE,OSRAM OSLON 3535,3030,Multi LED Lens

HX-C45Bx7-15(clear surface)
HX-C45Bx7-15L (beads surface)
HX-C45Bx7-15M (frosted surface)
¢45.0
H 10.0
15°

7in1- 45mm-25degree CREE XPE,OSRAM OSLON 3535,3030,Multi LED Lens

HX-C45Bx7-25(clear surface)
HX-C45Bx7-25L (beads surface)
HX-C45Bx7-25M (frosted surface)
¢45.0
H 10.0
25°

7in1- 45mm-30degree CREE XPE,OSRAM OSLON 3535,3030,Multi LED Lens
HX-C45Bx7-30(clear surface)
HX-C45Bx7-30L (beads surface)
HX-C45Bx7-30M (frosted surface)
¢45.0
H 10.0
30°
7in1- 45mm-38degree CREE XPE,OSRAM OSLON 3535,3030,Multi LED Lens
HX-C45Bx7-38(clear surface)
HX-C45Bx7-38L (beads surface)
HX-C45Bx7-38M (frosted surface)
¢45.0
H 10.0
38°
7in1- 45mm-45degree CREE XPE,OSRAM OSLON 3535,3030,Multi LED Lens
HX-C45Bx7-45(clear surface)
HX-C45Bx7-45L (beads surface)
HX-C45Bx7-45M (frosted surface)
¢45.0
H 10.0
45°
7in1- 45mm-60degree CREE XPE,OSRAM OSLON 3535,3030,Multi LED Lens
HX-C45Bx7-60(clear surface)
HX-C45Bx7-60L (beads surface)
HX-C45Bx7-60M (frosted surface)
¢45.0
H 10.0
60°
7in1- 45mm-75degree CREE XPE,OSRAM OSLON 3535,3030,Multi LED Lens
HX-C45Bx7-75(clear surface)
HX-C45Bx7-75L (beads surface)
HX-C45Bx7-75M (frosted surface)
¢45.0
H 10.0
75°
